I Tried Building a Video Streaming Engine in Rust

I started this experiment with a vague goal: understand how platforms turn an uploaded video into something that can play smoothly in a browser.

The first idea in my head was much smaller than the real problem. Save an MP4, expose it through an HTTP server, put the URL inside a <video> element, and that should be video streaming.

It is a form of delivery, but it avoids most of the engineering I wanted to learn. There is no processing lifecycle, no adaptive quality, no playlist, and no useful boundary between an uploaded source and a playback-ready video. It is closer to serving a large file than building a media pipeline.

That mistaken assumption gave the project its direction.

The complete experiment is available in mohxmd/stream-engine.

I did not want to implement a video codec. Encoding H.264 or AAC from first principles would be a completely different project, and it would hide the system around the encoder that I was actually curious about.

I chose a narrower boundary:

• FFprobe inspects the uploaded media.
• FFmpeg performs the expensive media work.
• Rust controls paths, processes, state, errors, and the HTTP API.
• HLS becomes the format between processing and playback.

The resulting flow looks like this:

upload
  -> save the source
  -> inspect its streams
  -> extract a thumbnail
  -> encode multiple renditions
  -> generate HLS playlists and segments
  -> expose a video resource
  -> serve the generated files

That division is important. Rust is not replacing FFmpeg here. It is making a repeatable application around FFmpeg.

I wanted the output to be visible and inspectable. HLS is useful for that because most of its structure is made from ordinary files.

A processed video in my project becomes:

media/hls/{video_id}/
├── thumbnail.jpg
├── master.m3u8
├── 720p/
│   ├── index.m3u8
│   └── segment_000.ts
├── 480p/
└── 360p/

The master playlist tells a player which renditions exist. Each rendition playlist points to a sequence of media segments. The player can then select a rendition based on its estimate of the available bandwidth.

This made adaptive streaming feel much less mysterious. The browser is not receiving a magical continuous stream from my Rust process. It is requesting playlists and media files over HTTP, then deciding what to fetch next.

The earliest useful version could have been a command that accepted one path and generated one folder. I moved beyond that because uploads introduce a lifecycle.

Immediately after an upload, the video is not ready. It moves through a small state machine:

pending -> processing -> ready
                      -> failed

That led to two different records in the Rust application.

A VideoJob represents internal work: the input path, output path, processing status, and an error if the worker fails. A Video represents what an API consumer cares about: a stable ID, original filename, source metadata, playback URL, thumbnail URL, and public status.

At first those types looked like duplicated state. They are related, but they answer different questions. A job asks, “What is the worker doing?” A video asks, “Can this resource be played?”

Keeping them separate also stopped implementation details such as filesystem paths from becoming part of the public video response.

Rust gave me useful friction. Paths could remain PathBuf values until I had to pass them to another process. FFprobe JSON could be deserialized into explicit structs. Shared state had to be synchronized instead of being treated as a global object that happened to work during local testing.

It also forced me to acknowledge the boundary between Axum’s asynchronous request handling and FFmpeg’s blocking process execution. Calling FFmpeg directly inside an async upload handler would occupy a runtime worker thread for the entire encode. The current version moves that work into tokio::task::spawn_blocking and updates the in-memory state around it.

This is enough for the experiment, but it is not a durable worker system. Restarting the process loses every Video and VideoJob record. The generated files remain on disk, while the API forgets that they exist.

The current project accepts a multipart upload, stores the source, probes its metadata, extracts a JPEG frame, generates three HLS renditions, creates a master playlist, and serves the output through Axum. It also exposes endpoints for reading a video, reading its internal job, and deleting its files.

That is a real local media-processing path. It is not a small Netflix or YouTube. Those systems add durable queues, distributed workers, object storage, authentication, observability, global delivery, and a large amount of failure handling that this experiment does not have.

Calling the project a streaming engine is useful as a description of its responsibility, not as a claim about its scale.

The first architecture answered where each responsibility belongs. The next question was more mechanical: what exactly must FFmpeg generate so that a player can move between different qualities without treating them as unrelated videos?
